IRIG-B to NTP & SNTP Converter
Product Description(IRIG-B to NTP Converter):
B E'S SY-B-N-01 is synchronized by a NTP Server and can be used as a time source for equipment that requires IRIG B for synchronization.
Optionally, the following output configurations are available:
SY-B-N-01 Irig-B to NTP Converter can transform IRIG-B DC(B002) to NTP/SNTP time code and finally to the server to synchronize the time.
Time input: BNC or RS-485/422 block terminal
Time output: NTP/SNTP(RJ-45 connector IEEE 802.3 - shielded data line) & RS-232(DB9 Connector)
Time accuracy: LAN: ±1ms
IRIG-B Time Format Support: IRIG-B DCLS(B002)
WAN: ±1~10ms
The maximum servers it can support: 22nos
Power input: 24V DC
Fuse: - 1 electronic
Output: - +5V / 3A
Total load ≤15 Watt
Other specs of IRIG-B to NTP Converter:
Work Temperature: –20~ 70℃
Storage: -40~ 125℃
Humidity: 85% max.
